HKB Grain Silo is widely used for grains storage such as wheat, corn, soybean, paddy, rice, soybean meal, barley, malt, sunflower seeds, rapeseeds, peanuts, flour, and other powder materials, oat, special grain, and seeds, etc.
Haokebang Machinery provides sincere services and professional barley silo, corn silos, wheat silos and other equipment to our customers. We have advanced production equipment and a professional technical team, and can customize suitable silo products according to customer needs.
The company pays attention to details and quality, and we carefully polish every aspect from design to production to ensure excellent product performance and outstanding performance.
When you buy our hot-dip galvanized steel barley silo, you will get cost-effective products and thoughtful after-sales service.
Barley silo are mainly used for storage of grain and other bulk materials. They have the characteristics of high strength, high performance, high cost performance, easy maintenance, and long life.
Haokebang Machinery specializes in the production of flat bottom grain silo, cone bottom silo, feed pellet silo and conveyor cleaning and control systems.
Mainly used for long-term storage of large quantities of grain, seeds, granular and powdery items.
Barley silo are light in weight and have low consumables, thus reducing basic costs.
The factory can formulate standard parts based on domestic materials to achieve standardization, generalization, and serialization. Prefabricated in the factory and assembled on site.
All parts of the barley silo are connected by bolts, which makes the installation quick and the construction period short.
Barley silos generally have professional supporting equipment, and can be equipped with supporting equipment such as entry, exit, ventilation, drying, temperature measurement, and fullness measurement according to the requirements to achieve the purpose of safe grain storage.
simple dismantling and maintenance, and partial board damage can be replaced.
appropriate service life.Generally, it is only 35% to 50% of the reinforced concrete silo, and its service life can reach more than 30 years.
The calculation standard for barley silo capacity is usually determined based on factors such as the type of barley silo, design parameters, and barley density.The following are some common calculation methods for barley warehouse capacity:
The calculation formula for bulk bungalow warehouse capacity is: warehouse capacity = building area × grain loading height × grain density × 95%.Among them, the building area is the actual floor area of the granary, the grain loading height is the vertical height of the barley silo after it is filled with grain, and the grain density is usually 750kg/m³.
The formula for calculating the capacity of a packaging bungalow is: Warehouse capacity = building area × stacking height × grain density × 71%.Among them, the building area is the actual floor area of the granary, the stacking height is the vertical height after the packed grain is stacked inside the barley silo, and the grain density is usually 750kg/m³.
The formula for calculating the storage capacity of a cylindrical granary is: storage capacity = 3.14 × inner diameter radius² × grain loading height × grain density.Among them, the inner diameter radius is the radius of the internal barrel wall of the grain silo, the grain filling height is the vertical height of the barley silo after filling with grain, and the grain density is usually 750kg/m³.
The calculation of the warehouse capacity of a star warehouse is relatively complex and usually needs to be calculated based on the specific structure of the star warehouse.A simplified calculation method is: warehouse capacity = every 4 star warehouses are equivalent to the warehouse capacity of 1 silo.
Scientifically speaking, the Grain Silo capacity should be measured with volume (m3). Even in the same grain Silo, the storage tons will be different for different grains with different densities. The following table is calculated based on a Silo density of 0.75kg/m3, and surely HKB customizes Silo systems unique for you.
| Most Popular Hopper Bottom Steel Silo Technical Specifications | ||||||||
| Capacity | 50Ton | 100Ton | 150Ton | 200Ton | 300Ton | 500Ton | 1000Ton | 1500Ton |
| Model | TCZK
03605 |
TCZK
04507 |
TCZK
05507 |
TCZK
06406 |
TCZK
07307 |
TCZK
07313 |
TCZK
11010 |
TCZK
12811 |
| Diameter(m) | 3.667 | 4.584 | 5.500 | 6.417 | 7.334 | 7.334 | 11.000 | 12.834 |
| Total Height(m) | 9.56 | 12.53 | 13.25 | 12.85 | 14.70 | 21.42 | 20.95 | 23.51 |
| Volume(m³)
Density:0.75ton/m³ |
69 | 150 | 222 | 273 | 415 | 699 | 1346 | 2039 |
| Most Popular Flat Bottom Steel Silo Technical Specifications | ||||||||
| Capacity | 1000Ton | 1500Ton | 2000Ton | 2500Ton | 3000Ton | 5000Ton | 8000Ton | 10000Ton |
| Model | TCK
10014 |
TCK
11915 |
TCK
13715 |
TCK
15514 |
TCK
15518 |
TCK
18321 |
TCK
24718 |
TCK
25621 |
| Diameter(m) | 10.084 | 11.918 | 13.750 | 15.584 | 15.584 | 18.334 | 24.751 | 25.668 |
| Total Height(m) | 18.69 | 20.34 | 20.87 | 20.30 | 24.78 | 28.60 | 26.99 | 30.60 |
| Volume(m³)
Density: 0.75ton/m³ |
1335 | 2009 | 2701 | 2467 | 4145 | 6693 | 10879 | 13484 |
Henan Haokebang Machinery Equipment Co., Ltd. specializes in the production of 100-10,000 ton hopper bottom and flat bottom corrugated galvanized steel grain Silo. According to various factors such as site, weather, and geology, we provide professional grain Silo design, equipped with elevators, unloading pits, pre-cleaner, conveyors, sweeping auger and other accessories to meet the diverse needs of customers.
