    Bean Silo

    Application

    HKB Grain Silo is widely used for grains storage such as wheat, corn, soybean, paddy, rice, soybean meal, barley, malt, sunflower seeds, rapeseeds, peanuts, flour, and other powder materials, oat, special grain, and seeds, etc.

    PDF Download
    Product Introduce

    HKB granary is mainly made of high-quality 275g/m2, 300g/m2, 350g/m2 hot-dip galvanized steel plates.It is widely used in the storage of wheat, corn, soybeans, rice, soybean meal, barley, malt, sunflower seeds, rapeseed, peanuts, flour and other powdery materials. It has corrosion resistance, high shock resistance, and long service life.
    Henan Haokebang Machinery Equipment Co., Ltd. is located in Henan, China.

    It specializes in producing grain processing equipment such as grain dryers, silos, tubular dryers, mesh belt dryers, and grain cleaning screens.

    It can provide users with a single equipment solution and equipment for a complete set of grain washing, drying, storage, and selection systems.

    As well as professional customized service technical support, reliable spare parts supply, and high-quality after-sales service. Look forward to working with you!

    bean warehouse

    Functions and features

    A bean silo is a facility used to store large amounts of grain and other items.Its main function is to protect stored items from the impact of the natural environment and ensure their safe preservation.

    Bean silo have the following functions and features:

    1.Moisture-proof and insect-proof:

    made of hot-dip galvanized steel plates, which effectively prevents moisture and insect pests from invading the grain.

    2.Ventilation and breathability:

    a well-designed ventilation system maintains grain quality.

    3.Safe and reliable:

    a sturdy and durable structure. Designed to ensure the stability and safety of the granary

    4.Easy to maintain:

    using an assembled structure to facilitate disassembly and repair, reducing maintenance costs

    features:

    1. Corrosion resistance:

    Bean silos have excellent corrosion resistance and can be used for a long time

    2. Environmental protection and health:

    made of environmentally friendly materials, it will not pollute food and has strong pressure resistance

    3. Solid structure:

    can withstand greater pressure. Easy to install: adopts assembled structure, saving time.

    4. Labor-saving and multi-functional:

    can be used for grain storage, material storage and other occasions.

    Applicable scene

    1. Rural grain storage:

    It can effectively protect farmers' grain from moisture and insect damage.

    2. Warehousing management of enterprises and institutions:

    It can be used to store various materials and improve the efficiency of warehousing management.

    3. Agricultural products Processing plant:

    as a storage device for semi-finished products or finished products to maintain stable product quality

    Technical Parameter

    Scientifically speaking, the bean Silo capacity should be measured with volume (m3). Even in the same grain Silo, the storage tons will be different for different grains with different densities. The following table is calculated based on a  Silo density of 0.75kg/m3, and surely HKB customizes  Silo systems unique for you.

    Most Popular Hopper Bottom Steel Silo Technical Specifications
    Capacity 50Ton 100Ton 150Ton 200Ton 300Ton 500Ton 1000Ton 1500Ton
    Model TCZK

    03605

    TCZK

    04507

    TCZK

    05507

    TCZK

    06406

    TCZK

    07307

    TCZK

    07313

    TCZK

    11010

    TCZK

    12811

    Diameter(m) 3.667 4.584 5.500 6.417 7.334 7.334 11.000 12.834
    Total Height(m) 9.56 12.53 13.25 12.85 14.70 21.42 20.95 23.51
    Volume(m³)

    Density:0.75ton/m³

    69 150 222 273 415 699 1346 2039
    Most Popular Flat Bottom Steel Silo Technical Specifications
    Capacity 1000Ton 1500Ton 2000Ton 2500Ton 3000Ton 5000Ton 8000Ton 10000Ton
    Model TCK

    10014

    TCK

    11915

    TCK

    13715

    TCK

    15514

    TCK

    15518

    TCK

    18321

    TCK

    24718

    TCK

    25621

    Diameter(m) 10.084 11.918 13.750 15.584 15.584 18.334 24.751 25.668
    Total Height(m) 18.69 20.34 20.87 20.30 24.78 28.60 26.99 30.60
    Volume(m³)

    Density: 0.75ton/m³

    1335 2009 2701 2467 4145 6693 10879 13484



    After-sale Service
    • – HKB provides advanced grain safety storage technology to assure your grain silo 100% quality stability.
    • grain silo Quality guarantee is one year after installation and commissioning or 18 months after leaving China Port. Maturity is the first.
    • – 7 days x 24 hours service, within 24 hours reply/solve of any technical issues upon request.
    • – Routinely telephone track to remove all might be problems grain silo or issues guarantying the whole system grain silo long-lasting safety and reliability.
    • – HKB will consider all other needs like customs clearance, sea delivery, insurance, customs tax benefit plan, documentation, etc. So our respected Users feel so relaxed and easy to get the grain silo system well.
