    flour silo

    Application

    The flour silo is a customized spliced ​​galvanized sheet granary produced by Coban Machinery Equipment Co., Ltd.The following will be described in detail from several perspectives such as product introduction, parameters, advantages and precautions.

    PDF Download
    Introduction to flour silo

    Flour silo, also known as flour steel silo, is a type of assembled steel silo or square silo widely used to store flour and other powder materials such as cement and powdered fuel ash.

    The flour silo produced by coban are designed with many years of industry experience, using computer design optimization software, and are refined with professional equipment and advanced technology.

    They are your ideal choice for storing and distributing flour and other powder materials.

    Flour silo

    Flour Silo Advantages

    1. From the perspective of air tightness:

    The flour silo produced by Coban use bending equipment during the rolling process, and have very good air tightness, which is equivalent to a vacuum. However, the air tightness of traditional silos is not as good as that of flour cylinders produced by Coban.

    2. From the perspective of storage function:

    Steel silo have different material configurations for various storages. Therefore, steel silo can store construction materials, fly ash, food, grain and oil, sewage and other materials. There are many types of storage, but the material storage range of traditional silo is relatively small.

    3. From the perspective of building materials:

    it is self-evident that traditional warehouses are made of reinforced concrete; as the name suggests, the steel plate flour silo is a steel plate silo with a light structure that is conducive to reducing infrastructure investment.

    4. From the perspective of construction period:

    traditional warehouses require material pouring and solidification time, so the total construction period is relatively long; however, the manufacturing of flour silos is relatively simple.Some types of flour silos can mostly be manufactured in factories and then installed directly on site, so the total construction time for flour silos is relatively short.

    Flour silo

    Precautions for using flour silo

    1. Cleaning:

    Before using a flour silo, it is essential to clean it thoroughly to ensure the quality and hygiene of the flour. To clean the silo, one should use a soft brush or vacuum cleaner to remove dust and impurities from the bin.

    2. Sealing:

    To ensure that the flour silo maintains good sealing performance, which is crucial for preventing the flour from becoming damp, moldy, or contaminated, one must regularly check the sealing gasket of the compartment cover during use. If the gasket is found to be damaged, it is imperative to replace it promptly.

    3. Storage:

    When storing flour, the remaining flour in the warehouse should be cleaned up to ensure that the new flour entering the warehouse will not be mixed with the old flour.At the same time, flour silos should be placed in a dry, well-ventilated place to prevent moisture and mold.

    4. Usage:

    The capacity of the flour silo should be selected according to actual needs and should not be too large or too small.Too large can lead to waste, while too small can lead to frequent cleaning.

    5. Maintenance:

    During use, the flour silo should be inspected and maintained regularly to ensure its normal operation and service life.If any damage or abnormality is found, you should deal with it in time or contact professionals for repair.

    5.at last

    when using flour silo, attention should be paid to hygiene, sealing, storage, usage and maintenance to ensure the quality and safety of flour.

    Flour silo technical parameters

    Scientifically speaking, the Grain Silo capacity should be measured with volume (m3). Even in the same grain Silo, the storage tons will be different for different grains with different densities. The following table is calculated based on a  Silo density of 0.75kg/m3, and surely HKB customizes  Silo systems unique for you.

    Most Popular Hopper Bottom Steel Silo Technical Specifications
    Capacity 50Ton 100Ton 150Ton 200Ton 300Ton 500Ton 1000Ton 1500Ton
    Model TCZK

    03605

    TCZK

    04507

    TCZK

    05507

    TCZK

    06406

    TCZK

    07307

    TCZK

    07313

    TCZK

    11010

    TCZK

    12811

    Diameter(m) 3.667 4.584 5.500 6.417 7.334 7.334 11.000 12.834
    Total Height(m) 9.56 12.53 13.25 12.85 14.70 21.42 20.95 23.51
    Volume(m³)

    Density:0.75ton/m³

    69 150 222 273 415 699 1346 2039
    Most Popular Flat Bottom Steel Silo Technical Specifications
    Capacity 1000Ton 1500Ton 2000Ton 2500Ton 3000Ton 5000Ton 8000Ton 10000Ton
    Model TCK

    10014

    TCK

    11915

    TCK

    13715

    TCK

    15514

    TCK

    15518

    TCK

    18321

    TCK

    24718

    TCK

    25621

    Diameter(m) 10.084 11.918 13.750 15.584 15.584 18.334 24.751 25.668
    Total Height(m) 18.69 20.34 20.87 20.30 24.78 28.60 26.99 30.60
    Volume(m³)

    Density: 0.75ton/m³

    1335 2009 2701 2467 4145 6693 10879 13484



    Flour silo Optional Accessories

    coban specializes in the production of 100-10,000 ton hopper bottom and flat bottom corrugated galvanized steel grain Silo. According to various factors such as site, weather, and geology, we provide professional grain Silo design, equipped with elevators, unloading pits, pre-cleaner, conveyors, sweeping auger and other accessories to meet the diverse needs of customers.

    Flour silo

    After-sale Service
    • – HKB provides advanced grain safety storage technology to assure your grain silo 100% quality stability.
    • grain silo Quality guarantee is one year after installation and commissioning or 18 months after leaving China Port. Maturity is the first.
    • – 7 days x 24 hours service, within 24 hours reply/solve of any technical issues upon request.
    • – Routinely telephone track to remove all might be problems grain silo or issues guarantying the whole system grain silo long-lasting safety and reliability.
    • – HKB will consider all other needs like customs clearance, sea delivery, insurance, customs tax benefit plan, documentation, etc. So our respected Users feel so relaxed and easy to get the grain silo system well.
