HKB Grain Silo is widely used for grains storage such as wheat, corn, soybean, paddy, rice, soybean meal, barley, malt, sunflower seeds, rapeseeds, peanuts, flour, and other powder materials, oat, special grain, and seeds, etc.

Inquiry [email protected] +8613598071775

PDF Download 

Product Introduce

silo company

Haokebang Silo Company specializes in the production of grain silos, tower grain dryers, tube dryers, mesh belt dryers, grain cleaning screens and other grain processing equipment.From grain cleaning, drying to storage, HKB provides you with one-stop service!The granaries produced by Haokebang Silo Company use high-quality 275g/m2, 300g/m2, and 350g/m2 hot-dip galvanized steel sheets, which are widely used in wheat, corn, soybeans, rice, corn, soybean meal, barley, malt, sunflower seeds, and rapeseed Seeds, peanuts, flour and other powdery materials, oats, special grains, seeds, etc.It has the characteristics of corrosion resistance, high shock resistance and long service life.Haokebang Machinery provides professional customized service technical support, reliable spare parts supply, and high-quality after-sales service.Looking forward to working with you!

Silo Characteristics

silo company

Economical and practical

The Silo produced by Haokebang Silo Company is economical and practical, with low investment, low operating cost, convenient entry and exit, and long service life.

Wide selection

The internal structure of the Silos produced by Haokebang Silo Company shape and position is designed with more than 20 patented technologies. It can be designed to be 2-40 meters. It can also be increased if there are special needs. The height and diameter are generally 1:1.1-1:1.5.We can also build a silo group of font, product font, device font, single row type and multi-row type according to the requirements of the site and factory.

Unique structure

The silo body is cylindrical, and the top and bottom of the warehouse are spherical, the base is barrel type.

Energy saving and environmental protection

The silo adopts patented dust removal technology during the warehousing and unloading process, which will not cause pollution to the surrounding environment.

Large storage capacity

The storage capacity of silos is very large. The capacity of a single warehouse can be divided into 10,000-500,000 tons, and large-capacity warehouse groups can also be formed.

Wide range of applications

Silo sare widely used for the storage of grain and feed, as well as cement, fly ash, petroleum, chemical raw materials, etc.

Technical Parameter

Scientifically speaking, the Grain Silo capacity should be measured with volume (m3). Even in the same grain Silo, the storage tons will be different for different grains with different densities. The following table is calculated based on a Silo density of 0.75kg/m3, and surely HKB customizes Silo systems unique for you.

Most Popular Hopper Bottom Steel Silo Technical Specifications
Capacity	50Ton	100Ton	150Ton	200Ton	300Ton	500Ton	1000Ton	1500Ton
Model	TCZK 03605	TCZK 04507	TCZK 05507	TCZK 06406	TCZK 07307	TCZK 07313	TCZK 11010	TCZK 12811
Diameter(m)	3.667	4.584	5.500	6.417	7.334	7.334	11.000	12.834
Total Height(m)	9.56	12.53	13.25	12.85	14.70	21.42	20.95	23.51
Volume(m³) Density:0.75ton/m³	69	150	222	273	415	699	1346	2039

Most Popular Flat Bottom Steel Silo Technical Specifications
Capacity	1000Ton	1500Ton	2000Ton	2500Ton	3000Ton	5000Ton	8000Ton	10000Ton
Model	TCK 10014	TCK 11915	TCK 13715	TCK 15514	TCK 15518	TCK 18321	TCK 24718	TCK 25621
Diameter(m)	10.084	11.918	13.750	15.584	15.584	18.334	24.751	25.668
Total Height(m)	18.69	20.34	20.87	20.30	24.78	28.60	26.99	30.60
Volume(m³) Density: 0.75ton/m³	1335	2009	2701	2467	4145	6693	10879	13484

After-sale Service

 – HKB provides advanced grain safety storage technology to assure your grain silo 100% quality stability.
 – grain silo Quality guarantee is one year after installation and commissioning or 18 months after leaving China Port. Maturity is the first.
 – 7 days x 24 hours service, within 24 hours reply/solve of any technical issues upon request.
 – Routinely telephone track to remove all might be problems grain silo or issues guarantying the whole system grain silo long-lasting safety and reliability.
 – HKB will consider all other needs like customs clearance, sea delivery, insurance, customs tax benefit plan, documentation, etc. So our respected Users feel so relaxed and easy to get the grain silo system well.
