    Silo Supplier

    Application

    HKB Grain Silo is widely used for grains storage such as wheat, corn, soybean, paddy, rice, soybean meal, barley, malt, sunflower seeds, rapeseeds, peanuts, flour, and other powder materials, oat, special grain, and seeds, etc.

    PDF Download
    Product Introduce

    Henan Haokebang Machinery Equipment Co., Ltd. is a professional silo supplier.The company specializes in the production of grain silos, corn silos, soybean silos, peanut silos, grain dryers and other grain processing equipment.From grain cleaning, drying to storage, provides you with a one-stop service!
    HKB silo supplier, the grain silo produced are made of high-quality 275g/m2, 300g/m2, 350g/m2 hot-dip galvanized steel sheets, which are widely used for wheat, corn, soybeans, rice, corn, soybean meal, barley , malt, sunflower seeds, rapeseed, peanuts, flour and other powdery materials as well as oats, special grains, seeds, etc.It has the characteristics of corrosion resistance, high shock resistance and long service life.
    Haokebang Machinery provides professional customized service technical support, reliable spare parts supply, and high-quality after-sales service. Look forward to working with you!

    Silo structure and classification

    1.Basic structure

    The basic structure of a silo includes wall panels, support systems, solid foundations and air circulation systems.Wall panels are usually composed of groove plates, hole plates, bolts, etc.The support system consists of upper structure, middle structure and lower structure.

    The foundation is usually made of poured concrete to ensure the silo’s stability.The air circulation system includes air inlets, exhaust outlets, ventilation ducts, etc., which are used to maintain air circulation in the silo and prevent moisture and mold.

    2. Classification

    (1) According to structural form

    1. Cylindrical silo: The cylinder is cylindrical and is often used to store grains, oil, etc.

    2. Polygonal silo: The cylinder is polygonal and is usually used to store powder, feed, etc.

    (2) Classification by use

    1. Grain storage silos: mainly used to store grains, oils, etc.

    2. Silos for storing feed: Mainly used for storing feed.

    (3) Classification by construction materials

    1. Concrete silo: usually used to store grain, oil, feed, etc.

    2. Steel silo: mainly used to store non-sticky materials, such as feed, etc.

    Technical Parameter

    Scientifically speaking, the Grain Silo capacity should be measured with volume (m3). Even in the same grain Silo, the storage tons will be different for different grains with different densities. The following table is calculated based on a  Silo density of 0.75kg/m3, and surely HKB customizes  Silo systems unique for you.

    Most Popular Hopper Bottom Steel Silo Technical Specifications
    Capacity 50Ton 100Ton 150Ton 200Ton 300Ton 500Ton 1000Ton 1500Ton
    Model TCZK

    03605

    TCZK

    04507

    TCZK

    05507

    TCZK

    06406

    TCZK

    07307

    TCZK

    07313

    TCZK

    11010

    TCZK

    12811

    Diameter(m) 3.667 4.584 5.500 6.417 7.334 7.334 11.000 12.834
    Total Height(m) 9.56 12.53 13.25 12.85 14.70 21.42 20.95 23.51
    Volume(m³)

    Density:0.75ton/m³

    69 150 222 273 415 699 1346 2039
    Most Popular Flat Bottom Steel Silo Technical Specifications
    Capacity 1000Ton 1500Ton 2000Ton 2500Ton 3000Ton 5000Ton 8000Ton 10000Ton
    Model TCK

    10014

    TCK

    11915

    TCK

    13715

    TCK

    15514

    TCK

    15518

    TCK

    18321

    TCK

    24718

    TCK

    25621

    Diameter(m) 10.084 11.918 13.750 15.584 15.584 18.334 24.751 25.668
    Total Height(m) 18.69 20.34 20.87 20.30 24.78 28.60 26.99 30.60
    Volume(m³)

    Density: 0.75ton/m³

    1335 2009 2701 2467 4145 6693 10879 13484
    After-sale Service
    • – HKB provides advanced grain safety storage technology to assure your grain silo 100% quality stability.
    • grain silo Quality guarantee is one year after installation and commissioning or 18 months after leaving China Port. Maturity is the first.
    • – 7 days x 24 hours service, within 24 hours reply/solve of any technical issues upon request.
    • – Routinely telephone track to remove all might be problems grain silo or issues guarantying the whole system grain silo long-lasting safety and reliability.
    • – HKB will consider all other needs like customs clearance, sea delivery, insurance, customs tax benefit plan, documentation, etc. So our respected Users feel so relaxed and easy to get the grain silo system well.
