    Soybean Meal Silo

    Application

    HKB Grain Silo is widely used for grains storage such as wheat, corn, soybean, paddy, rice, soybean meal, barley, malt, sunflower seeds, rapeseeds, peanuts, flour, and other powder materials, oat, special grain, and seeds, etc.

    PDF Download
    Product Introduce

    HKB Soybean Meal Silo is made of high-quality 275g/m2, 300g/m2, 350g/m2 hot-dip galvanized steel, widely used for grain storage such as wheat, corn, soybean, paddy, rice, soybean meal, barley, malt, sunflower seeds, rapeseed, peanuts, flour, and other powder materials, oat, special Silo, and seeds, etc. It has corrosion resistance, high shock resistance, and long service life.
    Henan Haokebang Machinery Equipment Co., Ltd. is located in Henan, China. It specializes in producing grain processing equipment such as grain dryers, silos, tubular dryers, mesh belt dryers, and grain cleaning screens. It can provide users with a single equipment solution and equipment for a complete set of grain washing, drying, storage, and selection systems. As well as professional customized service technical support, reliable spare parts supply, and high-quality after-sales service. Look forward to working with you!

    Soybean Meal Silo structure

    What three parts does a Soybean Meal Silo consist of?

    The silo body is composed of three parts: the silo roof, the silo body and the silo bottom.

    1. Soybean meal silo roof:

    The roof of Doubo silo is a spherical body, and the lower part is connected to the silo body.

    2. Silo body:

    The soybean meal silo body is welded by steel plates with varying thicknesses. The welded silo body is cylindrical. The thickness of the steel plates used in silos of 10,000 to 30,000 tons varies from bottom to top. They are 16, 14, 12, 10, 8, 6mm; the silos of 50,000 to 200,000 tons are 22, 20, 18, 16, 14, 12, 10, 8mm from bottom to top. There is a reinforcement connection system, and the entire silo body and reinforcement system are connected as a whole.

    3. discharging system:

    The soybean meal silo discharging system mainly consists of five parts: air supply pipe, exhaust pipe, gasification pipe in the warehouse, and discharging channel.

    Soybean meal silo advantages

    豆粕筒仓

    Soybean meal silo Low basic costs:

    silo are light in weight, have low requirements on foundations, and consume low steel, thus reducing basic costs.

    High degree of standardization:

    It can achieve a high degree of mechanization and automation, high production efficiency, and save production management personnel.

    Simple assembly and short construction period:

    All parts of the soybean meal silo are connected by bolts, prefabricated in the factory and assembled on site. The installation is quick and the construction period is short.

    Simple demolition and easy maintenance:

    The soybean meal silo is connected by bolts and can be relocated, and partial plate damage can be replaced.

    Low cost and long service life:

    Due to the use of multiple patented technologies, soybean meal silos can save a lot of building materials and land during the construction process.It is generally 35%-50% of reinforced concrete, and its service life is generally about 30 years.

    Application scenarios

    豆粕筒仓

    Spliced ​​galvanized sheet silo are suitable for grain storage needs in different fields such as farmland, farms, and storage bases.Whether used to store rice, wheat, corn and other grain crops, or for temporary storage or long-term storage, the soybean meal silo can provide a stable, safe and dry storage environment and effectively protect the quality of the grain.

    Technical Parameter

    Scientifically speaking, the Grain Silo capacity should be measured with volume (m3). Even in the same grain Silo, the storage tons will be different for different grains with different densities. The following table is calculated based on a  Silo density of 0.75kg/m3, and surely HKB customizes  Silo systems unique for you.

    Most Popular Hopper Bottom Steel Silo Technical Specifications
    Capacity 50Ton 100Ton 150Ton 200Ton 300Ton 500Ton 1000Ton 1500Ton
    Model TCZK

    03605

    TCZK

    04507

    TCZK

    05507

    TCZK

    06406

    TCZK

    07307

    TCZK

    07313

    TCZK

    11010

    TCZK

    12811

    直径(米) 3.667 4.584 5.500 6.417 7.334 7.334 11.000 12.834
    总高度(米) 9.56 12.53 13.25 12.85 14.70 21.42 20.95 23.51
    体积(立方米)

    密度:0.75吨/立方米

    69 150 222 273 第415章 699 1346 2039
    最流行的平底钢板仓技术规格
    容量 1000吨 1500吨 2000吨 2500吨 3000吨 5000吨 8000吨 10000吨
    模型 TCK

    10014

    TCK

    11915

    TCK

    13715

    TCK

    15514

    TCK

    15518

    TCK

    18321

    TCK

    24718

    TCK

    25621

    直径(米) 10.084 11.918 13.750 15.584 15.584 18.334 24.751 25.668
    总高度(米) 18.69 20.34 20.87 20.30 24.78 28.60 26.99 30.60
    体积(立方米)

    密度:0.75吨/立方米

    第1335章 2009年 2701 2467 4145 6693 10879 13484
    After-sale Service
    • – HKB provides advanced grain safety storage technology to assure your grain silo 100% quality stability.
    • grain silo Quality guarantee is one year after installation and commissioning or 18 months after leaving China Port. Maturity is the first.
    • – 7 days x 24 hours service, within 24 hours reply/solve of any technical issues upon request.
    • – Routinely telephone track to remove all might be problems grain silo or issues guarantying the whole system grain silo long-lasting safety and reliability.
    • – HKB will consider all other needs like customs clearance, sea delivery, insurance, customs tax benefit plan, documentation, etc. So our respected Users feel so relaxed and easy to get the grain silo system well.
